VariCAD is a professional CAD application that provides a wide range of features designed to help you create 3D or 2D drawings useful in the field of mechanical engineering. The user interface may seem a bit overwhelming at a first glance, but this is only because the program comes packed with many dedicated parameters. VariCAD gives users the possibility to insert objects from files (DWB, STP), copy, paste, or delete the selected components, drag and drop them into the working environment, undo or redo the last action, and change the colors of 2D or 3D objects. The 3D designs can be build with the use of different dedicated parameters designed to help you create shaded and wireframe views, rotate or zoom, rebuild 3D objects in case of internal data errors, create and edit solids, combine two solids in one object, define an object’s dimension or position within the corresponding solid, and apply geometric constrains.
User Interface and System Environment
VariCAD's Graphical User Interface (GUI) has been designed to allow quick and intuitive 3D/2D orientation. We carefully tailored and tuned the GUI to reflect the thought process of a designer, so that ideas can be captured and communicated with a minimal number of steps. All commands were created with a focus on ease of use. An intelligent cursor, numerous detection and selection modes, 2D construction lines, and the orthogonal grid are just some of the tools that make working with VariCAD so easy.
You can start by creating a 3D model and then use it to automatically create drawings files, or you can draw only in 2D. Designing in 3D is generally more "natural," in that it closely represents actual parts and assemblies. The 3D approach is usually more intuitive than 2D drafting. Models created in 3D are easily converted into conventional 2D documentation.
VariCAD provides a library of basic 3D solids (prism, cylinder, cone, etc.), which are easily modified by editing the original profile or parameters. Solids can also easily be created by profile rotation, extrusion, or lofting. More complex tools include rotation blending between two profiles, lofting between a circle and rectangle, and creation of helical surfaces.
Solids can be added or subtracted, thus forming Boolean trees representing real mechanical parts. Boolean operations have options for automatic trimming, or automatic removal of subtracted volumes. Predefined operations like hole drilling, face milling, groove milling and edge beveling/filleting are also available. Boolean trees are very easy to edit.
3D Tools - Assemblies, Groups, Parts etc.
VariCAD also provides tools for assembly support. If the link between a part and assembly is defined, any changes made to the part file are reflected in the assembly file and vice-versa. Linked copies can also be defined. In this case, editing of one object causes all its linked copies to be updated. Solid groups can be defined as well, making selection and visibility changes simple for multiple objects.
Crash Tests (Interferences)
One excellent feature of 3D modeling is component interference checking. VariCAD can check 3D assemblies for possible collisions (overlapping volume) between components.
VariCAD can calculate 2D section area, surface area, volume, mass, center of gravity, and moment of gyration. A library of mechanical calculations is also included, for standard parts used every day by mechanical designers. These mechanical parts include tension and compression springs, pre-stressed bolted connections, pins and parallel keys, grooved shafts, bearings, beams under combined stress (bending and torsion), spur and bevel gearing geometry, and belt drives.
Surface Development (Sheet Metal Unbending)
VariCAD can also create developed (flattened) surfaces of 3D solids. The XY coordinates of the developed surfaces can be saved to a text file for further processing. You can input bending coefficients in order to customize your calculations.
